Configure JWT authentication

Create an authentication rule

1. Log on to the API Gateway console.

2. In the left-side navigation pane, click Cloud-native API Gateway > Instance. In the top navigation bar, select a region.

3. On the Instance page, click the name of the target gateway instance.

4. In the left-side navigation pane, click Security Management > Global Authentication.

5. In the upper-left corner of the Global Authentication page, click Create Authentication. Configure the parameters, and then click OK.

   Parameter	Description
   Enable	Specifies whether to enable authentication for the Cloud-native API Gateway.
   Authentication Name	A custom name for the authentication rule.
   Authentication Type	Specifies the authentication type. JWT is supported by default.
   Issuer	The iss (issuer) claim of the JWT. This claim identifies the principal that issued the JWT.
   Sub	The sub (subject) claim of the JWT. This claim identifies the principal that is the subject of the JWT.
   JWKS	The JSON Web Key Set (JWKS) that contains the public key used to verify the JWT. The following format is an example: { "keys":[ { "e":"AQAB", "kid":"DHFbpoIUqrY8t2zpA2qXfCmr5VO5ZEr4RzHU_-envvQ", "kty":"RSA", "n":"xAE7eB6qugXyCAG3yhh7pkDkT65pHymX- P7KfIupjf59vsdo91bSP9C8H07pSAGQO1MV_xFj9VswgsCg4R6otmg5PV2 He95lZdHtOcU5DXIg_pbhLdKXbi66Gl VeK6ABZOUW3WYtnNHD-91gVuoeJT_DwtGGcp4ignkgXfkiEm4sw- 4sfb4qdt5oLbyVpmW6x9cfa7vs2WTfURiCrBoUqgBo_-4WTiULmmHSG ZHOjzwa8WtrtOQGsAFjIbno85jp6MnGGGZ PYZbDAa_b3y5u-YpW7ypZrvD8BgtKVjgtQgZhLAGezMt0ua3D RrWnKqTZ0BJ_EyxOGuHJrLsn00fnMQ" } ] }
   JWT Token	Specifies how to extract the JWT from the incoming request. Type: The location of the token parameter in the request. The default value is Header. Key: The name of the token parameter. Prefix: The prefix of the token parameter value. By default, the token is passed in the Authorization header with the Bearer prefix, for example: Authorization: Bearer token. Enable Passthrough: If this option is selected, the token parameter is passed through to the backend service.
   Authorization	Specifies the authorization mode. Whitelist Mode and Blacklist Mode are supported. Whitelist: Requests that match the specified hosts and paths can bypass authentication. All other requests require authentication. Blacklist: Requests that match the specified hosts and paths require authentication. All other requests pass through without authentication. Click Rule Condition to set the request domain name and path. Request Domain Name: The domain name in the request, which corresponds to hosts. Request Path: The API path in the request, which corresponds to paths.

View authentication rule details

1. Log on to the API Gateway console.

2. In the left-side navigation pane, click Cloud-native API Gateway > Instance. In the top navigation bar, select a region.

3. On the Instance page, click the name of the target gateway instance.

4. In the left-side navigation pane, click Security Management > Global Authentication.

5. On the Global Authentication page, find the target authentication rule and click Description in the Actions column. You can view the Basic Information and Authentication Configuration of the rule, and manage its Authorization Information.

   The Basic Information section includes the name and source (for example, JWT). The Authentication Configuration section includes fields such as Issuer, Type (for example, HEADER), the Enable Passthrough switch, Sub, Prefix (for example, Bearer), Key (for example, Authorization), and JWKS. The Authorization Information section supports the Whitelist mode, and the gateway evaluates multiple rule conditions with OR logic.

   In the Authorization Information section, click Create Authorization, and enter a Request Domain Name and Request Path in the dialog box to add a new authorization rule.

Verify the result

Return to the Global Authentication page. If the new authentication rule is listed, the creation was successful.

Related operations

You can also perform the following operations to manage gateway authentication rules:

• Enable an authentication rule: On the Global Authentication page, find the target authentication rule and click Enable in the Actions column.

• Disable an authentication rule: On the Global Authentication page, find the target authentication rule and click Close in the Actions column.

• Edit an authentication rule: On the Global Authentication page, find the target authentication rule and click Edit in the Actions column.

• Delete an authentication rule: On the Global Authentication page, find the target authentication rule and click Delete in the Actions column.

Related documentation

To learn about other authentication mechanisms, see Global Authentication.
