Image concatenation

Image information

• IMM project: test-project

• Source images:

  • oss://test-bucket/test-object.jpg1

  • oss://test-bucket/test-object.jpg2

• Output image: oss://test-bucket/test-target-object.jpg



Request example

{
    "ProjectName": "test-project",
    "Sources": "[{\"URI\": \"oss://test-bucket/test-object.jpg1\"},{\"URI\": \"oss://test-bucket/test-object.jpg2\"}]",
    "TargetURI": "oss://test-bucket/test-target-object.jpg"
}

Response example

{
    "TaskId": "ImageSplicing-1c73b551-381d-46cc-86ed-16905*****",
    "RequestId": "657DE82D-5960-0309-810C-639637*****",
    "EventId": "124-1S7JgMQdZ3kWQbmUqXxI3******"
}

Sample code (Python SDK)

The following example uses the IMM SDK for Python to concatenate images.

# -*- coding: utf-8 -*-
import sys
import os
from typing import List

from alibabacloud_imm20200930.client import Client as imm20200930Client
from alibabacloud_tea_openapi import models as open_api_models
from alibabacloud_imm20200930 import models as imm_20200930_models
from alibabacloud_tea_util import models as util_models
from alibabacloud_tea_util.client import Client as UtilClient


class Sample:
    def __init__(self):
        pass

    @staticmethod
    def create_client(
        access_key_id: str,
        access_key_secret: str,
    ) -> imm20200930Client:
        """
        Initialize the client with your AccessKey ID and AccessKey secret.
        @param access_key_id:
        @param access_key_secret:
        @return: Client
        @throws Exception
        """
        config = open_api_models.Config(
            access_key_id=access_key_id,
            access_key_secret=access_key_secret
        )
        # Specify the IMM endpoint. Replace the region as needed.
        config.endpoint = f'imm.cn-beijing.aliyuncs.com'
        return imm20200930Client(config)

    @staticmethod
    def main(
        args: List[str],
    ) -> None:
        # Read the AccessKey pair from environment variables.
        # Do not hardcode credentials in your code.
        # Use a RAM user instead of your Alibaba Cloud account for API calls.
        imm_access_key_id = os.getenv("AccessKeyId")
        imm_access_key_secret = os.getenv("AccessKeySecret")
        client = Sample.create_client(imm_access_key_id, imm_access_key_secret)
        sources_0 = imm_20200930_models.CreateImageSplicingTaskRequestSources(
            uri='oss://test-bucket/test-object.jpg1'
        )
        sources_1 = imm_20200930_models.CreateImageSplicingTaskRequestSources(
            uri='oss://test-bucket/test-object.jpg2'
        )
        create_image_splicing_task_request = imm_20200930_models.CreateImageSplicingTaskRequest(
            project_name='test-project',
            sources=[
                sources_0,
                sources_1
            ],
            target_uri='oss://test-bucket/test-target-object.jpg'
        )
        runtime = util_models.RuntimeOptions()
        try:
            # Call the API to create an image concatenation task.
            client.create_image_splicing_task_with_options(create_image_splicing_task_request, runtime)
        except Exception as error:
            # Handle errors as needed.
            UtilClient.assert_as_string(error.message)

    @staticmethod
    async def main_async(
        args: List[str],
    ) -> None:
        # Read the AccessKey pair from environment variables.
        # Do not hardcode credentials in your code.
        # Use a RAM user instead of your Alibaba Cloud account for API calls.
        imm_access_key_id = os.getenv("AccessKeyId")
        imm_access_key_secret = os.getenv("AccessKeySecret")
        client = Sample.create_client(imm_access_key_id, imm_access_key_secret)
        sources_0 = imm_20200930_models.CreateImageSplicingTaskRequestSources(
            uri='oss://test-bucket/test-object.jpg1'
        )
        sources_1 = imm_20200930_models.CreateImageSplicingTaskRequestSources(
            uri='oss://test-bucket/test-object.jpg2'
        )
        create_image_splicing_task_request = imm_20200930_models.CreateImageSplicingTaskRequest(
            project_name='test-project',
            sources=[
                sources_0,
                sources_1
            ],
            target_uri='oss://test-bucket/test-target-object.jpg'
        )
        runtime = util_models.RuntimeOptions()
        try:
            # Call the API asynchronously.
            await client.create_image_splicing_task_with_options_async(create_image_splicing_task_request, runtime)
        except Exception as error:
            # Handle errors as needed.
            UtilClient.assert_as_string(error.message)


if __name__ == '__main__':
    Sample.main(sys.argv[1:])

OSS charges

For pricing details, see OSS产品定价.

IMM charges

For pricing details, see IMM billable items.
