Flip images

Usage

Use the ?x-oss-process=image/flip, [value] parameter. OSS then processes the image in real time and returns the result.

• image/flip: The flip operation.

• [value]: The flip direction. For more information about the valid values, see Parameters.

package com.aliyun.oss.demo;
import com.aliyun.oss.*;
import com.aliyun.oss.common.auth.*;
import com.aliyun.oss.common.comm.SignVersion;
import com.aliyun.oss.model.GeneratePresignedUrlRequest;
import java.net.URL;
import java.util.Date;

public class Demo {
    public static void main(String[] args) throws Throwable {
        // The endpoint of the China (Hangzhou) region is used as an example. Specify the actual endpoint.
        String endpoint = "https://oss-cn-hangzhou.aliyuncs.com";
        // Obtain access credentials from environment variables. Before you run the sample code, make sure that the OSS_ACCESS_KEY_ID and OSS_ACCESS_KEY_SECRET environment variables are configured.
        EnvironmentVariableCredentialsProvider credentialsProvider = CredentialsProviderFactory.newEnvironmentVariableCredentialsProvider();
        // Specify the bucket name. Example: examplebucket.
        String bucketName = "examplebucket";
        // Specify the full path of the object. If the image is not in the root directory of the bucket, you must include the full path of the image. Example: exampledir/exampleobject.jpg.
        String objectName = "exampledir/exampleobject.png";
        // Specify the region where the bucket is located. For example, if the bucket is in the China (Hangzhou) region, set Region to cn-hangzhou.
        String region = "cn-hangzhou";

        // Create an OSSClient instance.
        // When the OSSClient instance is no longer used, call the shutdown method to release resources.
        ClientBuilderConfiguration clientBuilderConfiguration = new ClientBuilderConfiguration();
        clientBuilderConfiguration.setSignatureVersion(SignVersion.V4);
        OSS ossClient = OSSClientBuilder.create()
                .endpoint(endpoint)
                .credentialsProvider(credentialsProvider)
                .clientConfiguration(clientBuilderConfiguration)
                .region(region)
                .build();

        try {
            // Flip the image vertically.
            String style = "image/flip,0";
            // Specify the expiration time of the signed URL.
            Date expiration = new Date(new Date().getTime() + 3600 * 1000L );
            GeneratePresignedUrlRequest req = new GeneratePresignedUrlRequest(bucketName, objectName, HttpMethod.GET);
            req.setExpiration(expiration);
            req.setProcess(style);
            URL signedUrl = ossClient.generatePresignedUrl(req);
            System.out.println(signedUrl);
        } catch (OSSException oe) {
            System.out.println("Caught an OSSException, which means your request made it to OSS, "
                    + "but was rejected with an error response for some reason.");
            System.out.println("Error Message:" + oe.getErrorMessage());
            System.out.println("Error Code:" + oe.getErrorCode());
            System.out.println("Request ID:" + oe.getRequestId());
            System.out.println("Host ID:" + oe.getHostId());
        } catch (ClientException ce) {
            System.out.println("Caught an ClientException, which means the client encountered "
                    + "a serious internal problem while trying to communicate with OSS, "
                    + "such as not being able to access the network.");
            System.out.println("Error Message:" + ce.getMessage());
        } finally {
            if (ossClient != null) {
                ossClient.shutdown();
            }
        }
    }
}

# -*- coding: utf-8 -*-
import oss2
from oss2.credentials import EnvironmentVariableCredentialsProvider

# Obtain access credentials from environment variables. Before you run the sample code, make sure that the OSS_ACCESS_KEY_ID and OSS_ACCESS_KEY_SECRET environment variables are configured.
auth = oss2.ProviderAuthV4(EnvironmentVariableCredentialsProvider())

# Specify the bucket name.
bucket = 'examplebucket'

# Specify the endpoint of the region where the bucket is located. The China (Hangzhou) region is used as an example.
endpoint = 'https://oss-cn-hangzhou.aliyuncs.com'

# Specify the general-purpose region ID of Alibaba Cloud.
region = 'cn-hangzhou'
bucket = oss2.Bucket(auth, endpoint, bucket, region=region)

# Specify the name of the source image. If the image is not in the root directory of the bucket, you must include the full path of the image. Example: exampledir/exampleobject.jpg.
key = 'exampledir/exampleobject.png'

# Specify the expiration time in seconds.
expire_time = 3600

# Flip the image vertically.
image_process = 'image/flip,0'

# Generate a signed URL that contains the image processing parameter.
url = bucket.sign_url('GET', key, expire_time, params={'x-oss-process': image_process}, slash_safe=True)

# Print the signed URL.
print(url)

<?php
if (is_file(__DIR__ . '/../autoload.php')) {
    require_once __DIR__ . '/../autoload.php';
}
if (is_file(__DIR__ . '/../vendor/autoload.php')) {
    require_once __DIR__ . '/../vendor/autoload.php';
}

use OSS\Credentials\EnvironmentVariableCredentialsProvider;
use OSS\OssClient;

// Obtain access credentials from environment variables. Before you run the sample code, make sure that the OSS_ACCESS_KEY_ID and OSS_ACCESS_KEY_SECRET environment variables are configured.
$provider = new EnvironmentVariableCredentialsProvider();
// Set yourEndpoint to the endpoint of the region where the bucket is located. For example, if the bucket is in the China (Hangzhou) region, set the endpoint to https://oss-cn-hangzhou.aliyuncs.com.
$endpoint = "yourEndpoint";
// Specify the bucket name. Example: examplebucket.
$bucket= "examplebucket";
// Specify the full path of the object. Example: exampledir/exampleobject.jpg. The full path cannot contain the bucket name.
$object = "exampledir/exampleobject.jpg";

$config = array(
        "provider" => $provider,
        "endpoint" => $endpoint,
        "signatureVersion" => OssClient::OSS_SIGNATURE_VERSION_V4,
        "region"=> "cn-hangzhou"
    );
    $ossClient = new OssClient($config);

// Generate a signed URL that contains the image processing parameter. The URL is valid for 3600 seconds and can be used to access the image from a browser.
$timeout = 3600;

$options = array(
    // Flip the image vertically.
    OssClient::OSS_PROCESS => "image/flip,0");

$signedUrl = $ossClient->signUrl($bucket, $object, $timeout, "GET", $options);
print("url: \n" . $signedUrl);

package main

import (
	"fmt"
	"os"

	"github.com/aliyun/aliyun-oss-go-sdk/oss"
)

func HandleError(err error) {
	fmt.Println("Error:", err)
	os.Exit(-1)
}

func main() {
	// Obtain access credentials from environment variables. Before you run the sample code, make sure that the OSS_ACCESS_KEY_ID and OSS_ACCESS_KEY_SECRET environment variables are configured.
	provider, err := oss.NewEnvironmentVariableCredentialsProvider()
	if err != nil {
		fmt.Println("Error:", err)
		os.Exit(-1)
	}

	// Create an OSSClient instance.
	// Set yourEndpoint to the endpoint of the bucket. For example, if the bucket is in the China (Hangzhou) region, set the endpoint to https://oss-cn-hangzhou.aliyuncs.com. Specify the actual endpoint for other regions.
	// Set yourRegion to the region where the bucket is located. For example, if the bucket is in the China (Hangzhou) region, set the region to cn-hangzhou. Specify the actual region for other regions.
	clientOptions := []oss.ClientOption{oss.SetCredentialsProvider(&provider)}
	clientOptions = append(clientOptions, oss.Region("yourRegion"))
	// Set the signature version.
	clientOptions = append(clientOptions, oss.AuthVersion(oss.AuthV4))
	client, err := oss.New("yourEndpoint", "", "", clientOptions...)
	if err != nil {
		HandleError(err)
	}

	// Specify the name of the bucket where the image is stored. Example: examplebucket.
	bucketName := "examplebucket"
	bucket, err := client.Bucket(bucketName)
	if err != nil {
		HandleError(err)
	}
	// Specify the name of the image. If the image is not in the root directory of the bucket, you must include the full path of the file. Example: exampledir/exampleobject.jpg.
	ossImageName := "exampledir/exampleobject.png"
	// Generate a signed URL and set the expiration time to 3600s. The maximum validity period is 32400 seconds.
	// Flip the image vertically.
	signedURL, err := bucket.SignURL(ossImageName, oss.HTTPGet, 3600, oss.Process("image/flip,0"))
	if err != nil {
		HandleError(err)
	} else {
		fmt.Println(signedURL)
	}
}

Parameters

Action: flip

The following table lists the flip parameters.

Examples

Related API operations

To process images by using REST API requests, add the image processing parameter to the GetObject request. You must calculate the signature manually. For more information, see Signature V4 (recommended).

GET /oss.jpg?x-oss-process=image/flip,0  HTTP/1.1
Host: oss-example.oss-cn-hangzhou.aliyuncs.com
Date: Fri, 28 Oct 2024 06:40:10 GMT
Authorization: SignatureValue
