Guide to adding identifiers to AI-generated images

Updated at:
Copy as MD
Product
My Favorites

This document describes how to add data identifiers to images.

Background

According to the "Measures for Identifying AI-Generated and Synthesized Content", starting from September 1, 2025, all content generated by artificial intelligence (AI), such as images, audio, and videos, must include both visible and invisible identifiers. These identifiers can be metadata tags or digital watermarks. This ensures that the source of the content is traceable and identifiable.The Secure Access Service Edge (SASE) platform provides the CreateWmEmbedTask API. This API helps enterprises manage content identifiers efficiently and meet compliance requirements.

Image watermark parameter descriptions

Name

Type

Required

Description

Example

WmType

string

Yes

The watermark type. Valid values:

  • PureDocument: Document watermark.

  • PureImage: Image watermark.

  • PureAudio: Audio watermark.

  • PureVideo: Video watermark.

  • AigcDocument: AIGC document watermark.

  • AigcImage: AIGC image watermark.

  • AigcAudio: AIGC audio watermark.

  • AigcVideo: AIGC video watermark.

PureImage

Filename

string

Yes

The name of the file to embed the watermark in. The backend uses the file extension to verify the file type.

abc****.pdf

FileUrl

string

Yes

The URL from which the file can be downloaded. The URL must be accessible over the public network.

https://example.com/abc****.pdf

WmInfoSize

long

No

The bit width of the watermark information. The default value is 32. This parameter must be the same for both embedding and fetching. For example, if you use a 40-bit software development kit (SDK) for embedding, you must also set this parameter to 40 for fetching.

Enumeration values:

  • 32: 32.

  • 40: 40.

  • 64: 64.

32

WmInfoUint

string

No

The watermark information in decimal format. If you set this parameter, you cannot set WmInfoBytesB64.

The value range depends on the WmInfoSize parameter:

  • If WmInfoSize is 32, the value range is 1 to 4294967295.

  • If WmInfoSize is 40, the value range is 1 to 1099511627775.

  • If WmInfoSize is 64, the value range is 1 to 18446744073709551615.

123***

WmInfoBytesB64

string

No

The watermark information as a Base64-encoded string. If you set this parameter, you cannot set WmInfoUint.

aGVsbG8gc2F*****

ImageEmbedLevel

long

No

Image watermark parameter. A larger value provides higher robustness but reduces visual quality. The default value is 2. Valid values: 0 to 4.

2

ImageEmbedJpegQuality

long

No

Image watermark parameter. The desired JPEG compression quality factor for the output image. The default value is 95. Valid values: 1 to 100.

95

ImageControl

object

No

Image watermark control parameters.

TextVisibleControl

object

No

Image text watermark control parameters.

VisibleText

string

No

The text for the watermark. The format is a UTF-8 string.

Watermark text

Mode

string

No

The display mode for the text watermark. Valid values:

  • pos: Fixed position mode.

  • repeat: Tiled mode.

  • top-left: Top-left mode.

  • top-right: Top-right mode.

  • bottom-left: Bottom-left mode.

  • bottom-right: Bottom-right mode.

pos

Opacity

integer

No

The opacity of the text watermark. Valid values: 1 to 255. A larger value means the watermark is more opaque.

255

FontSize

long

No

The font size of the text watermark. A larger value means a larger font.

30

FontColor

string

No

The color of the text watermark. The format is an RGB color value, such as 0xFFFFFF or #FFFFFF. For example, 0x000000 or #000000 represents black.

#FF0000

Angle

long

No

The clockwise rotation angle of the text watermark in degrees. The value range is 0 to 360.

30

PosX

long

No

This parameter is active when Mode is set to pos. It controls the horizontal position of the text watermark in pixels, with the top-left corner as the origin.

0

PosY

long

No

This parameter is active when Mode is set to pos. It controls the vertical position of the text watermark in pixels, with the top-left corner as the origin.

0

SpaceX

long

No

This parameter is active when Mode is set to repeat. It controls the horizontal spacing of the tiled text watermark.

30

SpaceY

long

No

This parameter is active when Mode is set to repeat. It controls the vertical spacing of the tiled text watermark.

0

PosAx

float

No

The horizontal anchor point of the text watermark. The value range is 0 to 1. If (PosAx, PosAy) is (0, 0), the anchor is the top-left corner of the text. If the value is 0.5, the anchor is the center of the text. If the value is (1, 1), the anchor is the bottom-right corner of the text.

0

PosAy

float

No

The vertical anchor point of the text watermark. The value range is 0 to 1. If (PosAx, PosAy) is (0, 0), the anchor is the top-left corner of the text. If the value is 0.5, the anchor is the center of the text. If the value is (1, 1), the anchor is the bottom-right corner of the text.

0

Visible

boolean

No

Visibility:

true: The item is displayed.

false: The item is not displayed.

true

Margin

object

No

This parameter is active when Mode is set to top-left, top-right, bottom-left, or bottom-right. It specifies the margin.

Top

float

No

This parameter is active when Mode is set to top-left or top-right. It specifies the top margin.

0

Right

float

No

This parameter is active when Mode is set to top-right or bottom-right. It specifies the right margin.

0

Bottom

float

No

This parameter is active when Mode is set to bottom-left or bottom-right. It specifies the bottom margin.

0

Left

float

No

This parameter is active when Mode is set to top-left or bottom-left. It specifies the left margin.

0

LogoVisibleControl

object

No

Logo watermark control parameters.

LogoBase64

string

No

The logo watermark in Base64 format. The logo file must be a PNG image converted to Base64 format.

iVBORw0KGgoAAAANSUhEUgAAAMgAAADICA*************

Mode

string

No

The display mode for the logo watermark. Valid values:

  • pos: Fixed position mode.

  • repeat: Tiled mode.

  • top-left: Top-left mode.

  • top-right: Top-right mode.

  • bottom-left: Bottom-left mode.

  • bottom-right: Bottom-right mode.

pos

Opacity

integer

No

The opacity of the logo watermark. Valid values: 1 to 255. A larger value means the watermark is more opaque.

255

Angle

long

No

The clockwise rotation angle of the logo watermark in degrees. The value range is 1 to 360.

30

PosX

long

No

This parameter is active when Mode is set to pos. It controls the horizontal position of the visible watermark in pixels, with the top-left corner as the origin.

0

PosY

long

No

This parameter is active when Mode is set to pos. It controls the vertical position of the visible watermark in pixels, with the top-left corner as the origin.

0

SpaceX

long

No

This parameter is active when Mode is set to repeat. It controls the horizontal spacing of the tiled visible watermark.

30

SpaceY

long

No

This parameter is active when Mode is set to repeat. It controls the vertical spacing of the tiled visible watermark.

30

PosAx

float

No

The horizontal anchor point of the logo watermark. The value range is 0 to 1. If (PosAx, PosAy) is (0, 0), the anchor is the top-left corner of the text. If the value is 0.5, the anchor is the center of the text. If the value is (1, 1), the anchor is the bottom-right corner of the text.

0

PosAy

float

No

The vertical anchor point of the logo watermark. The value range is 0 to 1. If (PosAx, PosAy) is (0, 0), the anchor is the top-left corner of the text. If the value is 0.5, the anchor is the center of the text. If the value is (1, 1), the anchor is the bottom-right corner of the text.

0

Visible

boolean

No

Visibility:

true: The item is displayed.

false: Not displayed.

true

Margin

object

No

This parameter is active when Mode is set to top-left, top-right, bottom-left, or bottom-right. It specifies the margin.

Top

float

No

This parameter is active when Mode is set to top-left or top-right. It specifies the top margin.

0

Right

float

No

This parameter is active when Mode is set to top-right or bottom-right. It specifies the right margin.

0

Bottom

float

No

This parameter is active when Mode is set to bottom-left or bottom-right. It specifies the bottom margin.

0

Left

float

No

This parameter is active when Mode is set to top-left or bottom-left. It specifies the left margin.

0

MetadataControl

object

No

Metadata control parameters. This parameter is active when WmType is set to PureImage or AigcImage.

XmpKvBase64

string

No

The metadata in Base64 format.

QUlHQzp7IkxhYmVsIjoiMSIsIkNvbnRlbnRQcm9kdWNlciI6IkFMSVlVTi1UT05HWUlRSUFOV0VOIiwiUHJvZHVjZUlEIjoiNzQ3MjAzNzQyMDczNDIiLCJQcm9wYWdhdG9yIjoiQUxJWVVOLVRPTkdZSVFJQU5XRU4iLCJQcm9wYXRvcklEIjoiNDU3MjM0NjciLCJSZXNlcnZlQ29kZSI6IjU2MDQ1NzM3In0=

Enable

boolean

No

Specifies whether to enable this feature.

true: It is displayed.

false: The item is not displayed.

true

Metadata format description

The XmpKvBase64 field requires metadata in Base64 format. Before you encode the metadata in Base64, it must meet the following format requirements.

KEY

Description

Example value

Label

Indicates whether the content is generated by AI:

  • 1: The content is generated and synthesized by AI.

  • 2: (For distribution platforms only) The content may be generated and synthesized by AI.

  • 3: (For distribution platforms only) The content is suspected to be generated and synthesized by AI.

1

ContentProducer

The code or name of the service provider, used to identify the content producer.

  • Required fields

    • Digits 1-2: The identity format definition code, which records the version of the encoding rules. For codes created using this guide, this is fixed to "00".

    • Digit 3: The entity type. Set to "1" for an organization or "2" for an individual.

    • Digit 4: Set to "1" when an organization's entity is attached using its Unified Social Credit Code.

    • Digits 5-22: The organization's entity code, which is its Unified Social Credit Code.

  • Extension fields

    • Digit 23: Set to "1" for generation and synthesis services, or "2" for content distribution.

    • Digits 24-27: The service or model number. This must be unique.

For more information, see the Network Security Standard Practice Guide.

001191******M000100Y43

ProduceID

The content production number. This is a unique identifier used by the production platform to trace synthesized content.

123456

ReserveCode1

Reserved field.

This can store information for the generation and synthesis service provider to implement their own security protection and ensure content and identity integrity. A hashing mechanism based on ContentProducer and ProduceID can be used for secure storage and verification of key information.

d41d8cd98f00b204e9800998ecf8427e

ContentPropagator

The name, number, or code of the distribution platform. For services that provide AI-generated and synthesized content, this can be the same as ContentProducer.

001191******M000100Y43

PropatorID

The content distribution number. This is a unique number assigned by the distribution platform to the distributed generated and synthesized content.

123456

ReserveCode2

Reserved field.

This can be used by the content distribution service provider to implement their own security protection and ensure content and identity integrity. A hashing mechanism based on ContentProducer and ProduceID can be used for secure storage and verification of key information.

d41d8cd98f00b204e9800998ecf8427e

For example, consider a production platform company named AA with the Unified Social Credit Code 91******M000100Y43.

AIGC: {
    "Label": "1",
    "ContentProducer": "001191******M000100Y43",
    "ProduceID": "123456",
    "ReservedCode1": "d41d8cd98f00b204e9800998ecf8427e",
    "ContentPropagator": "001191******M000100Y43",
    "PropagateID": "123456",
    "ReservedCode2": "d41d8cd98f00b204e9800998ecf8427e"
}

Example

{
    "ImageControl": {
        "MetadataControl": {
            "XmpKvBase64": "QUlHQzp7IkxhYmVsIjoiMSIsIkNvbnRlbnRQcm9kdWNlciI6IjAwMTE5MSoqKioqKk0wMDAxMDBZNDMiLCJQcm9kdWNlSUQiOiIxMjM0NTYiLCJSZXNlcnZlZENvZGUxIjoiZDQxZDhjZDk4ZjAwYjIwNGU5ODAwOTk4ZWNmODQyN2UiLCJDb250ZW50UHJvcGFnYXRvciI6IjAwMTE5MSoqKioqKk0wMDAxMDBZNDMiLCJQcm9wYWdhdGVJRCI6IjEyMzQ1NiIsIlJlc2VydmVkQ29kZTIiOiJkNDFkOGNkOThmMDBiMjA0ZTk4MDA5OThlY2Y4NDI3ZSJ9",
            "Enable": true
        },
        "TextVisibleControl": {
            "VisibleText": "AI Generated",
            "Mode": "bottom-right",
            "Opacity": 255,
            "FontSize": 40,
            "FontColor": "#FFFFFF",
            "Visible": true,
            "Margin": {
                "Right": 20,
                "Bottom": 20
            }
        }
    },
    "WmType": "PureImage",
    "Filename": "IMG_1937.PNG",
    "FileUrl": "https://fangtingtest.oss-cn-hangzhou.aliyuncs.com/IMG_1937.PNG?Expires=1757020815&OSSAccessKeyId=TMP.3Kpr************&Signature=hwGQSxItTDS1EeFPGTzB6R3ME6Y%3D",
    "WmInfoSize": 32,
    "WmInfoUint": "123456"
}

Result
