图片免训数字人接入指南

更新时间：
复制为 MD 格式
产品详情
我的收藏

该文档详细描述了通过API创建图片免训数字人的完整流程，包括背景和图片素材上传、数字人创建及对话配置组装。

重要

图片免训数字人可用于实时对话，不可用于播报视频合成和直播。

操作流程

  1. 使用获取上传凭证API获取图片素材上传凭证并上传图片素材。

  2. 通过创建免训图片数字人API设置变量值，创建图片免训数字人。

1 上传图片素材

  1. 使用获取上传凭证API获取图片素材上传凭证。

  2. 上传图片素材，图片素材文件要求如下：

    1. 格式： jpg、jpeg、png。

    2. 分辨率：最小分辨率：400px，最大分辨率：7000px。

    3. 文件大小：不超过10M。

    4. 宽高比：9:16。

1.1 获取图片素材上传凭证

private static GetUploadPolicyResponseBody.GetUploadPolicyResponseBodyData upload(Client client, String type, File file) throws Exception {
    //获取上传凭证
    GetUploadPolicyRequest getUploadPolicyRequest = new GetUploadPolicyRequest();
    getUploadPolicyRequest.setType("INPUT_INFER_PIC");
    GetUploadPolicyResponse uploadPolicy = client.getUploadPolicy(getUploadPolicyRequest);
    GetUploadPolicyResponseBody.GetUploadPolicyResponseBodyData data = uploadPolicy.getBody().getData();
    System.out.println("获取上传凭证:" + JSON.toJSONString(data));
    return data;
}

1.2 上传训练图片素材

private static void uploadFile(GetUploadPolicyResponseBody.GetUploadPolicyResponseBodyData data, File file) throws IOException {
    CloseableHttpClient httpClient = HttpClients.createDefault();
    try {
        HttpPost uploadFile = new HttpPost("https://" + data.getOssPolicy().getHost());
        MultipartEntityBuilder builder = MultipartEntityBuilder.create();

        ContentType contentType = ContentType.create("multipart/form-data", Consts.UTF_8);

        // 添加OSS所需的表单字段
        builder.addTextBody("key", data.getOssKey() + "/" + file.getName(), contentType);
        builder.addTextBody("policy", data.getOssPolicy().getPolicy(), contentType);
        builder.addTextBody("OSSAccessKeyId", data.getOssPolicy().getAccessId(), contentType);
        builder.addTextBody("signature", data.getOssPolicy().getSignature(), contentType);
        // 添加文件
        builder.addBinaryBody("file", Files.newInputStream(file.toPath()), ContentType.IMAGE_PNG, file.getName());
        HttpEntity multipart = builder.build();
        uploadFile.setEntity(multipart);
        CloseableHttpResponse response = httpClient.execute(uploadFile);
        try {
            HttpEntity responseEntity = response.getEntity();
            System.err.println("Upload result: " + response.getStatusLine());
            if (responseEntity != null) {
                String responseString = EntityUtils.toString(responseEntity);
                System.err.println("Response content: " + responseString);
            }
            EntityUtils.consume(responseEntity);
        } finally {
            response.close();
        }
    } finally {
        httpClient.close();
    }
}

1.3 上传示例


2 创建图片免训数字人

说明

如果图片存在内容安全问题或人物不符合形象要求，创建免训图片数字人会失败。

private static CreateNoTrainPicAvatarResponse createNoTrainPicAvatar(Client client,
                                                                     File imageFile,
                                                                     GetUploadPolicyResponseBody.GetUploadPolicyResponseBodyData imageData) throws Exception {
    CreateNoTrainPicAvatarRequest chatSessionConfigRequest = new CreateNoTrainPicAvatarRequest();
    //设置形象表情表现力为普通或热情
    chatSessionConfigRequest.setExpressiveness("NORMAL");//"ENTHUSIASTIC"
    chatSessionConfigRequest.setName("数字人");
    //设置性别
    chatSessionConfigRequest.setGender("MALE");//"FEMALE"
    chatSessionConfigRequest.setImageOssPath(imageData.getOssKey() + "/" + imageFile.getName());
    //设置形象背景为透明或不透明
    chatSessionConfigRequest.setTransparent(true);
    CreateNoTrainPicAvatarResponse chatAvatar = client.createNoTrainPicAvatar(chatSessionConfigRequest);
    System.out.println("创建免训图片数字人:" + JSON.toJSONString(chatAvatar.body.getData()));
    return chatAvatar;
 }

图片免训数字人完整调用示例代码

引入SDK

<dependency>
    <groupId>com.aliyun</groupId>
    <artifactId>lingmou20250527</artifactId>
    <version>1.5.3</version>
</dependency>

示例代码

import com.alibaba.fastjson.JSON;
import com.aliyun.lingmou20250527.Client;
import com.aliyun.lingmou20250527.models.*;
import com.aliyun.teaopenapi.models.Config;
import org.apache.http.Consts;
import org.apache.http.HttpEntity;
import org.apache.http.client.methods.CloseableHttpResponse;
import org.apache.http.client.methods.HttpPost;
import org.apache.http.entity.ContentType;
import org.apache.http.entity.mime.MultipartEntityBuilder;
import org.apache.http.impl.client.CloseableHttpClient;
import org.apache.http.impl.client.HttpClients;
import org.apache.http.util.EntityUtils;

import java.io.File;
import java.io.IOException;
import java.nio.file.Files;

public class Demo {

    public static void main(String[] args) throws Exception {

        Client client = Demo.getInstance();
        //1.上传形象素材
        File imageFile = new File("D:\\images\\criticize_counselor_clear.webp");
        GetUploadPolicyResponseBody.GetUploadPolicyResponseBodyData imageData = upload(client, "INPUT_INFER_PIC", imageFile);
        //2.创建免训图片数字人形象，如图片存在内容安全问题或人不符合形象要求会失败
        CreateNoTrainPicAvatarRequest chatSessionConfigRequest = new CreateNoTrainPicAvatarRequest();
        //设置形象表情表现力为普通或热情
        chatSessionConfigRequest.setExpressiveness("NORMAL");//"ENTHUSIASTIC"
        chatSessionConfigRequest.setName("数字人");
        //设置性别
        chatSessionConfigRequest.setGender("MALE");//"FEMALE"
        chatSessionConfigRequest.setImageOssPath(imageData.getOssKey() + "/" + imageFile.getName());
        //设置形象背景为透明或不透明
        chatSessionConfigRequest.setTransparent(true);
        CreateNoTrainPicAvatarResponse chatAvatar = client.createNoTrainPicAvatar(chatSessionConfigRequest);
        System.out.println("创建对话免训图片数字人:" + JSON.toJSONString(chatAvatar.body.getData()));

    }

    private static GetUploadPolicyResponseBody.GetUploadPolicyResponseBodyData upload(Client client, String type, File file) throws Exception {
        //获取上传凭证
        GetUploadPolicyRequest getUploadPolicyRequest = new GetUploadPolicyRequest();
        getUploadPolicyRequest.setType(type);
        GetUploadPolicyResponse uploadPolicy = client.getUploadPolicy(getUploadPolicyRequest);
        GetUploadPolicyResponseBody.GetUploadPolicyResponseBodyData data = uploadPolicy.getBody().getData();
        System.out.println("获取上传凭证:" + JSON.toJSONString(data));
        // HttpClient上传文件
        uploadFile(data, file);
        return data;
    }


    private static void uploadFile(GetUploadPolicyResponseBody.GetUploadPolicyResponseBodyData data, File file) throws IOException {
        CloseableHttpClient httpClient = HttpClients.createDefault();
        try {
            HttpPost uploadFile = new HttpPost("https://" + data.getOssPolicy().getHost());
            MultipartEntityBuilder builder = MultipartEntityBuilder.create();

            ContentType contentType = ContentType.create("multipart/form-data", Consts.UTF_8);

            // 添加OSS所需的表单字段
            builder.addTextBody("key", data.getOssKey() + "/" + file.getName(), contentType);
            builder.addTextBody("policy", data.getOssPolicy().getPolicy(), contentType);
            builder.addTextBody("OSSAccessKeyId", data.getOssPolicy().getAccessId(), contentType);
            builder.addTextBody("signature", data.getOssPolicy().getSignature(), contentType);
            // 添加文件
            builder.addBinaryBody("file", Files.newInputStream(file.toPath()), ContentType.IMAGE_PNG, file.getName());
            HttpEntity multipart = builder.build();
            uploadFile.setEntity(multipart);
            CloseableHttpResponse response = httpClient.execute(uploadFile);
            try {
                HttpEntity responseEntity = response.getEntity();
                System.err.println("Upload result: " + response.getStatusLine());
                if (responseEntity != null) {
                    String responseString = EntityUtils.toString(responseEntity);
                    System.err.println("Response content: " + responseString);
                }
                EntityUtils.consume(responseEntity);
            } finally {
                response.close();
            }
        } finally {
            httpClient.close();
        }
    }

    public static Client getInstance() throws Exception {
        String accessKeyId = "xxx";
        String accessKeySecret = "yyy";
        String endpoint = "lingmou.cn-beijing.aliyuncs.com";

        Config config = new Config();
        // noinspection AklessInspection
        config.setAccessKeyId(accessKeyId);
        config.setAccessKeySecret(accessKeySecret);
        config.setEndpoint(endpoint);
        return new Client(config);
    }
}

形象创建错误码

    DETECT_FAILED("图像检测失败"),
    DETECT_NOT_PASS("图像检测不通过"),
    CONTENT_RISK("您的图片涉及平台限制内容，请重新上传"),
    NO_HUMAN_BODY("未检测到人脸"),
    MULTI_HUMAN_BODY("请上传单个形象图片"),
    INVALID_HUMAN_PROPORTION("形象在照片中比例过大/过小"),
    INVALID_IMAGE_SIZE("图片大小不符合要求"),
    INVALID_PERSON_VAGUE("请上传更清晰的照片"),
    INVALID_BODY_ORIENTATION("请确保身体朝向正面"),
    FACE_INCOMPLETE("请确保脸部完整"),
    INVALID_FACE_ORIENTATION("请确保脸部朝向正面"),
