iOS SDK UI 自定义配置说明

自定义UI颜色和icon图标

目前仅支持自定义引导页和活体认证页的颜色和icon图标。

接口说明

iOS SDK中提供了自定义UI颜色和icon图标的接口：setCustomUI。

/**
 * 设置自定义UI
 * @param customConfig
 * 传入JSON文件路径或者JSON字符串
 * @param type
 * 传入的config类型path或者json
 * @param completion配置文件结果回调
* */
+ (void)setCustomUI:(nonnull NSString *)configuration type:(nonnull NSString *)type completion:(void(^)(BOOL success, NSError *error))completion;

• 参数说明

  名称	类型	说明
  configuration	NSString	配置自定义入参的类型： json：传入JSON字符串。 path：传入JSON文件的沙盒路径。
  type	NSString	根据传入的configuration，选择传入json或path。
  completion	block	结果信息回调。 success为YES表示设置成功。 success为NO表示设置的内容存在问题，具体请查看对应返回的error说明。

• 返回值：无。

示例代码

//传入文件路径
NSString *path = @"/var/mobile/Containers/Data/Application/C9DF10E6-7AB4-4C66-A180-DF1080C93F72/Documents/uiCustom.json";
[AliyunFaceAuthFacade setCustomUI:path type:@"path" completion:^(BOOL success, NSError * _Nonnull error) {
	NSLog(@"%@",error.localizedDescription);
}];

//传入JSON字符串
NSString *jsonString = @"{""\"guideConfig\": \"#FF0000\""}";
[AliyunFaceAuthFacade setCustomUI:jsonString type:@"json" completion:^(BOOL success, NSError * _Nonnull error) {
	NSLog(@"%@",error.localizedDescription);
}];

字段定义

字段列表

{
  "guideConfig": {
    "titleColor": "#111111",
    "titleBackPath": "",
    "titleBackBase64": "",
    "titleClosePath": "",
    "titleCloseBase64": "",
    "bannerImg": "",
    "agrtUnSelColor": "#c5c5c5",
    "agrtSelBgColor": "#ff6a00",
    "agrtAgreeColor": "#333333",
    "agrtColor": "#ff6a00",
    "startBtnColor": "#ffffff",
    "agrtBotTipsColor": "#333333",
    "startBtnDisColor": "#ffffff",
    "startBtnBgColor": "#ff6a00",
    "startBtnDisBgColor": "#d9d9d9",
    "elderBtnDisColor": "#ffffff",
    "elderBtnBgColor": "#f0f0f0",
    "elderBtnDisBgColor": "#d9d9d9",
    "exitBtnColor": "#333333",
    "exitBtnBgColor": "#ffffff",
    "elderBtnColor": "#ff6a00",
    "rareFormEntBtnColor": "#ff6a00",
    "permissionToastBgColor": "#ffffff",
    "permissionToastTitleColor": "#000000",
    "permissionToastMsgColor": "#000000",
    "dialogExitTitleColor": "#000000",
    "dialogExitMsgColor": "#000000",
    "dialogExitCancelColor": "#0E83E6",
    "dialogExitConfirmColor": "#0E83E6",
    "dialogPermissionFailedTitleColor": "#000000",
    "dialogPermissionFailedMsgColor": "#000000",
    "dialogPermissionFailedConfirmColor": "#0E83E6",
    "dialogSupportFailedTitleColor": "#000000",
    "dialogSupportFailedMsgColor": "#000000",
    "dialogSupportFailedConfirmColor": "#0E83E6",
    "dialogNetworkFailedTitleColor": "#000000",
    "dialogNetworkFailedMsgColor": "#000000",
    "dialogNetworkFailedConfirmColor": "#0E83E6"
  },
  "faceConfig": {
    "faceBgColor": "#FFFFFF",
    "faceTitleColor": "#000000",
    "circleTxtBgAlpha": "0.25",
    "dialogBgAlpha": "0.25",
    "faceProgressStartColor": "#dfe6eb",
    "faceProgressEndColor": "#FF6A00",
    "circleTxtColor": "#ffffff",
    "exitIconPath": "",
    "exitIconBase64": "",
    "submitTextColor": "#E4E4E4",
    "submitLoadingIconBase64": "",
    "submitLoadingIconPath": "",
    "dialogExitTitleColor": "#000000",
    "dialogExitMsgColor": "#000000",
    "dialogExitCancelColor": "#0E83E6",
    "dialogExitConfirmColor": "#0E83E6",
    "dialogTimeOutTitleColor": "#000000",
    "dialogTimeOutMsgColor": "#000000",
    "dialogTimeOutConfirmColor": "#0E83E6",
    "dialogNetworkFailedTitleColor": "#000000",
    "dialogNetworkFailedMsgColor": "#000000",
    "dialogNetworkFailedConfirmColor": "#0E83E6",
    "dialogArchSysFailedTitleColor": "#000000",
    "dialogArchSysFailedMsgColor": "#000000",
    "dialogArchSysFailedConfirmColor": "#0E83E6",
    "dialogTooManyRetriesTitleColor": "#000000",
    "dialogTooManyRetriesMsgColor": "#000000",
    "dialogTooManyRetriesConfirmColor": "#0E83E6",
    "dialogInterruptTitleColor": "#000000",
    "dialogInterruptMsgColor": "#000000",
    "dialogInterruptConfirmColor": "#0E83E6",
    "dialogInterruptCancelColor": "#0E83E6",
    "dialogSDKErrTitleColor": "#000000",
    "dialogSDKErrMsgColor": "#000000",
    "dialogSDKErrConfirmColor": "#0E83E6",
    "dialogCamOpenFailedTitleColor": "#000000",
    "dialogCamOpenFailedMsgColor": "#000000",
    "dialogCamOpenFailedConfirmColor": "#0E83E6",
    "dialogCamOpenFailedCancelColor": "#0E83E6",
    "noticeIconPath": "",
    "noticeTxtColor": "#1677FF",
    "noticeBgColor": "#0F1677FF"
  },
  "docConfig": {
    "stafeLineDefaultColor": "#673AB7",
    "stageLineSelectedColor": "#ff0000",
    "stageSelectedTxtColor": "ff0000",
    "stageDefaultTxtColor": "#673AB7",
    "infoTipsColor": "673AB7",
    "bottomTipsColor": "673AB7",
    "takeRequestColor": "#ff0000",
    "takeRequestTitleColor": "#ff0000",
    "infoNoticeBgColor": "ff0000",
    "infoNoticeTxtColor": "ff0000",
    "infoCertNameColor": "#ff0000",
    "infoCertNoColor": "#ff0000",
    "resultCertNameColor": "#673AB7",
    "resultCertNoColor": "#673AB7",
    "infoHintColor": "00ff00",
    "nextBgColor": "#ff0000",
    "nextTxtColor": "#ff0000",
    "nextDisableBgColor": "#ff0000",
    "nextDisableTxtColor": "#ff0000",
    "dialogIdentifyFailTxtColor": "#ff0000",
    "dialogIdentifyFailHintColor": "#ff0000",
    "dialogIdentifyFailConfirmColor": "#ff0000",
    "dialogFailTooManyExitColor": "#ff0000",
    "dialogExitConfirmColor": "#ff0000",
    "dialogExitCancelColor": "#ff0000",
    "takePhotoTipColor": "",
    "takePhotoCoverAlpha": "0.85",
    "dialogIdentifyFailTitleColor": "#ff0000",
    "stageSelectedBgPath": "",
    "stageDefaultBgPath": "",
    "stageDoneBgPath": "",
    "takeRequestExitIconPath": "",
    "takeRequestImgPath": "",
    "takeEnterIconPath": "",
    "frontDefaultImgPath": "",
    "backDefaultImgPath": "",
    "infoNoticeIconPath": "",
    "dialogIdentifyFailExitIconPath": "",
    "dialogIdentifyFailImgPath": "",
    "takePhotoExitIconPath": "",
    "takePhotoIconPath": "",
    "flashOnIconPath": "",
    "flashOffIconPath": "",
    "photoRetakeIconPath": "",
    "photoConfirmIconPath": "",
    "takePhotoRectPath": "",
    "livenessImgPath": "",
    "livenessLoadingImgPath": "",
    "exitIconPath": "",
    "stageDoneBgBase64": "",
    "takeRequestExitIconBase64": "",
    "stageSelectedBgBase64": "",
    "stageDefaultBgBase64": "",
    "takeRequestImgBase64": "",
    "takeEnterIconBase64": "",
    "frontDefaultImgBase64": "",
    "backDefaultImgBase64": "",
    "infoNoticeIconBase64": "",
    "dialogIdentifyFailExitIconBase64": "",
    "dialogIdentifyFailImgBase64": "",
    "takePhotoExitIconBase64": "",
    "takePhotoIconBase64": "",
    "flashOnIconBase64": "",
    "flashOffIconBase64": "",
    "photoRetakeIconBase64": "",
    "photoConfirmIconBase64": "",
    "takePhotoRectBase64": "",
    "livenessImgBase64": "",
    "livenessLoadingImgBase64": "",
    "exitIconBase64": ""
  }
}

对应列表

展开折叠面板查看字段详细说明。

NSMutableDictionary  *extParams = [NSMutableDictionary new];
[extParams setValue:self forKey:@"currentCtr"];
//如需打开刷脸页业务提示开关（默认可不设置），请设置此项,需要结合自定义UI的配置文件使用
[extParams setValue:@"true" forKey:ZIM_EXT_PARAMS_KEY_NEED_FACE_NOTICE];
[ZolozFaceAuthFacade verifyWith:self.certifyId extParams:extParams onCompletion:^(ZIMResponse *response) {
}];

文案自定义

目前仅支持自定义引导页和活体认证页的展示文案。

接口说明

SDK中提供了自定义UI的接口：setCustomTxtConfig。

/**
 * 设置自定义文案
 * @param customConfig
 * 传入json文件路径或者json字符串
 * @param type
 * 传入的config类型path或者json
 * @param completion配置文件结果回调
* */
+ (void)setCustomLanguage:(nonnull NSString *)configuration type:(nonnull NSString *)type completion:(void(^)(BOOL success, NSError *error))completion;

• 参数说明

  名称	类型	说明
  configuration	NSString	配置自定义入参的类型： json：传入JSON字符串。 path：传入JSON文件的沙盒路径。
  type	NSString	根据传入的configuration，选择传入json或path。
  completion	block	结果信息回调。 success为YES表示设置成功。 success为NO表示设置的内容存在问题，具体请查看对应返回的error说明。

• 返回值：无。

示例代码

//传入文件路径
NSString *path = @"/var/mobile/Containers/Data/Application/C9DF10E6-7AB4-4C66-A180-DF1080C93F72/Documents/customLanguage.json";
[AliyunFaceAuthFacade setCustomLanguage:path type:@"path" completion:^(BOOL success, NSError * _Nonnull error) {
	NSLog(@"%@",error.localizedDescription);
}];

//传入json字符串
NSString *jsonString = @"{""\"titleText\": \"刷脸认证\""}";
[AliyunFaceAuthFacade setCustomLanguage:jsonString type:@"json" completion:^(BOOL success, NSError * _Nonnull error) {
	NSLog(@"%@",error.localizedDescription);
}];

字段定义

字段列表

{
  "guideConfig": {
    "titleText": "刷脸认证",
    "agrtTopTipsText": "请先勾选协议",
    "agrtAgreeText": "同意",
    "agrtText": "《认证服务协议》",
    "agrtBotTipsText": "同意认证后，将获取您的摄像头权限用于人脸识别验证身份",
    "startBtnText": "开始认证",
    "elderBtnText": "长辈模式认证",
    "exitBtnText": "暂不认证",
    "authPermissionSDKName": "实人认证",
    "authPermissionAPPName": "阿里云实人认证",
    "authPermissionCamera": "相机",
    "authPermissionAudio": "录音",
    "authPermissionScreenEvidence": "录屏",
    "authPermissionToastTitle": "",
    "authPermissionToastMsg": "",
    "dialogExitTitle": "确定退出吗?",
    "dialogExitMsg": "露个脸就能通过",
    "dialogExitConfirm": "确定",
    "dialogExitCancel": "取消",
    "dialogPermissionFailedTitle": "认证失败",
    "dialogPermissionFailedMsg": "请确认相关权限已开启后再次发起",
    "dialogPermissionFailedConfirm": "确认",
    "dialogNetworkFailedTitle": "网络不给力",
    "dialogNetworkFailedMsg": "请检查网络",
    "dialogNetworkFailedConfirm": "确定",
    "dialogSupportFailedTitle": "当前系统不支持刷脸",
    "dialogSupportFailedMsg": "刷脸仅在高版本及以上系统可用",
    "dialogSupportFailedConfirm": "确定"
  },
  "faceConfig": {
    "faceNotFound": "没有检测到脸",
    "faceTooFar": "靠近一点",
    "faceTooClose": "离远一点",
    "faceNotIn": "把脸移入圈内",
    "badPitch": "请正对手机",
    "badYaw": "请正对手机",
    "faceTooMore": "请保持单人操作",
    "faceIsMoving": "再清晰一点",
    "faceBrightless": "脸部亮一点",
    "faceBadQuality": "请露出正脸",
    "eyesOnScreen": "请注视屏幕",
    "blink": "眨眨眼",
    "leftYaw": "向左摇头",
    "rightYaw": "向右摇头",
    "stackTime": "请保持不动",
    "isBlur": "再清晰一点",
    "faceInitTxt": "请正对屏幕",
    "faceTitleBlink": "拿起手机，眨眨眼",
    "leftYawLiveness": "拿起手机，向左摇头",
    "rightYawLiveness": "拿起手机，向右摇头",
    "photinusCommTips": "请把脸移入圈内保持不动",
    "processing": "正在处理",
    "dialogTimeOutTitle": "操作超时",
    "dialogTimeOutMsg": "正对手机，更容易成功",
    "dialogTimeOutConfirm": "再试一次",
    "dialogInterruptTitle": "验证中断",
    "dialogInterruptConfirm": "再试一次",
    "dialogInterruptCancel": "退出",
    "dialogTooManyRetriesTitle": "本次操作失败",
    "dialogTooManyRetriesMsg": "刷脸失败次数过多，请稍后再试",
    "dialogTooManyRetriesConfirm": "我知道了",
    "dialogExitTitle": "确定退出吗?",
    "dialogExitMsg": "露个脸就能通过",
    "dialogExitConfirm": "确定",
    "dialogExitCancel": "取消",
    "dialogCamOpenFailedTitle": "摄像头打开异常",
    "dialogCamOpenFailedMsg": "请重启app或手机后再次尝试",
    "dialogCamOpenFailedConfirm": "确定",
    "dialogCamOpenFailedCancel": "取消",
    "dialogArchSysFailedTitle": "当前系统不支持刷脸",
    "dialogArchSysFailedMsg": "刷脸仅在高版本及以上系统可用",
    "dialogArchSysFailedConfirm": "确定",
    "dialogSDKErrTitle": "本次操作失败",
    "dialogSDKErrMsg": "抱歉，系统出错了，请再试一次",
    "dialogSDKErrConfirm": "确定",
    "dialogNetworkFailedTitle": "网络不给力",
    "dialogNetworkFailedMsg": "请检查网络",
    "dialogNetworkFailedConfirm": "确定",
    "verifyNotice": "您正在进行实人认证，请确保本人操作！"
  },
  "docConfig": {
    "stageFrontTips": "人像面",
    "stageBackTips": "国徽面",
    "stageLivenessTips": "实人认证",
    "frontInfoTips": "拍摄人像面",
    "frontInfoBottomTips": "证件人像面",
    "backInfoBottomTips": "证件国徽面",
    "backInfoTips": "拍摄国徽面",
    "takeRequireTxt": "拍摄要求",
    "takeRequireTitle": "拍摄要求",
    "resultCheckTips": "请确认以下身份信息，如有误请点击修改",
    "certNameTitle": "姓名",
    "certNameHint": "请输入姓名",
    "certNoTitle": "身份证号",
    "certNoHint": "请输入身份证号",
    "nextTxt": "下一步",
    "confirmTxt": "确认身份信息无误",
    "livenessTips": "实人认证",
    "livenessMsg": "拍摄您本人人脸，请确保正对手机，光线充足",
    "livenessLoadingMsg": "即将进入刷脸页...",
    "dialogIdentityFailTitle": "识别失败",
    "dialogIdentityFailRequireTitle": "证件图像未符合要求",
    "dialogIdentityFailRequireMsg": "请按要求拍摄本人有效身份证",
    "dialogIdentityFailRetry": "重新拍摄",
    "dialogNetworkTimeOutTitle": "识别超时",
    "dialogNetworkTimeOutMsg": "网络连接超时，请重新识别",
    "dialogNetworkTimeOutConfirm": "重新识别",
    "dialogNetworkTimeOutCancel": "退出",
    "identityLoadingMsg": "识别中",
    "dialogExitTitle": "确定退出吗？",
    "dialogExitMsg": "拍张照就能通过",
    "dialogExitCancel": "取消",
    "dialogExitConfirm": "确定",
    "dialogTooManyRetriesTitle": "识别失败次数过多",
    "dialogTooManyRetriesMsg": "请退出后重试",
    "dialogTooManyRetriesConfirm": "退出",
    "takeFrontTips": "拍摄身份证人像面",
    "takeBackTips": "拍摄身份证国徽面"
  }
}

字段详细说明

展开折叠面板查看字段详细说明。

NSMutableDictionary  *extParams = [NSMutableDictionary new];
[extParams setValue:self forKey:@"currentCtr"];
//如需打开刷脸页业务提示开关（默认可不设置），请设置此项,需要结合自定义UI的配置文件使用
[extParams setValue:@"true" forKey:ZIM_EXT_PARAMS_KEY_NEED_FACE_NOTICE];
[ZolozFaceAuthFacade verifyWith:self.certifyId extParams:extParams onCompletion:^(ZIMResponse *response) {
}];

合规权限提醒

SDK为了保证基础功能的运行需要向客户申请对应功能的权限，为了保证您的应用对客户展示合规，SDK内部提供了权限获取以及使用说明提醒弹窗，该功能默认关闭，当您需要使用时请通过verify接口进行开启。

开关接口

接口说明

请参考对应方案的Verify接口函数定义。

示例代码

NSMutableDictionary *extParams = [NSMutableDictionary dictionary];
//需要使用权限toast
[extParams setValue:@"true" forKey:ZIM_EXT_PARAMS_KEY_NEED_PERMISSION_TOAST];
[extParams setValue:@(3000) forKey:ZIM_EXT_PARAMS_KEY_PERMISSION_TOAST_DURATION];
.....
[AliyunFaceAuthFacade verifyWith:certifyId extParams:extParams onCompletion:^(ZIMResponse *response) {

}];

弹窗自定义接口

当SDK默认的弹框不足以满足业务诉求时，您可以通过DTFUICustomProtocol接口自定义弹窗能力。

接口说明

请参考对应方案的Verify接口函数定义。

/**
 * 实现Protocol方法
 * @param permission，需要获取的权限
 * @param serviceType，需要获取的权限类型
 * return：BOOL类型，当您需要自行处理弹窗时，返回YES即可，否则SDK会根据开关配置决定是否进行弹窗
* */
- (BOOL)showPermissionViewWithPermission:(NSArray *)permission serviceType:(DTFServiceType)serviceType{
 //实现弹窗样式并展示
 return YES;
}

• 参数说明

  名称	类型	说明
  permission	NSArray	当前请求权限的列表。
  serviceType	String	当前请求权限的业务。 FACE：活体业务。 OCR：证件业务。 WISH：多因子意愿业务。

• 返回值：bool类型。当您需要自行处理弹窗时，返回设置YES；若需要默认弹窗，则返回值设置NO。

示例代码

@interface PermissionView : NSObject<DTFUICustomProtocol>

- (BOOL)showPermissionViewWithPermission:(NSArray *)permission serviceType:(DTFServiceType)serviceType;

@end



@implementation PermissionView

/**
 * 实现Protocol方法
 * @param permission
 * 需要获取的权限
 * @param serviceType
 * 需要获取的权限类型
 * return：BOOL类型，当您需要自行处理弹窗时，返回YES即可，否则SDK会根据开关配置决定是否进行弹窗
* */
- (BOOL)showPermissionViewWithPermission:(NSArray *)permission serviceType:(DTFServiceType)serviceType{
 //实现弹窗样式并展示
 return YES;
}
@end

NSMutableDictionary *extParams = [NSMutableDictionary dictionary];
PermissionView *permissionView = [PermissionView alloc]init];
// 把实现了Protocol的对象传入
[extParams setValue:permissionView forKey:@"UICustomProtocol"];
.....
[AliyunFaceAuthFacade verifyWith:certifyId extParams:extParams onCompletion:^(ZIMResponse *response) {

}];
