Android SDK UI自定义配置说明

自定义UI颜色和icon图标

目前仅支持自定义引导页和活体认证页的颜色和icon图标。

接口说明

Android SDK中提供了自定义UI颜色和icon图标的接口：setCustomUIConfig。

/**
 * @description 此接口用于设置自定义UI。
 * @param {int} paramType 参数类型，可传范围（
 *        ZIMFacade.ZIM_EXT_PARAMS_VAL_ZIM_EXT_PARAMS_CONFIG_ASSETS_NAME
 *        /ZIMFacade.ZIM_EXT_PARAMS_VAL_ZIM_EXT_PARAMS_CONFIG_FILE_PATH
 *        /ZIMFacade.ZIM_EXT_PARAMS_VAL_ZIM_EXT_PARAMS_CONFIG_FILE_JSON）。
 * @param {String} param 参数值，paramType相对应的值。
 * @return 配置文件检测出的异常信息。
 */
public String setCustomUIConfig(int paramType, String param) {
 ...
}

• 参数说明：

  名称	类型	说明
  paramType	int	配置自定义入参的类型： ZIMFacade.ZIM_EXT_PARAMS_VAL_ZIM_EXT_PARAMS_CONFIG_ASSETS_NAME： 传入App assets文件类型，param需要传入assets文件名称。 ZIMFacade.ZIM_EXT_PARAMS_VAL_ZIM_EXT_PARAMS_CONFIG_FILE_PATH： 传入设备本地路径，params需要传入配置文件的设备绝对路径地址。 ZIMFacade.ZIM_EXT_PARAMS_VAL_ZIM_EXT_PARAMS_CONFIG_FILE_JSON： 传入JSON字符串，params需传入JSON格式的数据。
  param	String	与paramType配套调用。

• 返回值：String类型，当SDK对param内容解析遇到错误或出现异常信息时会通过提示信息的方式返回。当配置参数无效时，请重点关注返回值信息。

示例代码

//传入文件路径
File file = new File(getFilesDir() + "/dtf/config_test/DTFConsumUIConfig.json");
String path = file.getAbsolutePath();
int paramType = ZIMFacade.ZIM_EXT_PARAMS_VAL_ZIM_EXT_PARAMS_CONFIG_FILE_PATH;
customUIErrMsg = zimFacade.setCustomUIConfig(paramType, path);

//传入assets文件名
String fileName = "DTFConsumUIConfig.json";
int paramType = ZIMFacade.ZIM_EXT_PARAMS_VAL_ZIM_EXT_PARAMS_CONFIG_ASSETS_NAME;
customUIErrMsg = zimFacade.setCustomUIConfig(paramType, fileName);

//传入JSON字符串
String jsonConfig="";
int paramType = ZIMFacade.ZIM_EXT_PARAMS_VAL_ZIM_EXT_PARAMS_CONFIG_FILE_JSON;
customUIErrMsg = zimFacade.setCustomUIConfig(paramType, jsonConfig);

字段定义

字段列表

{
  "guideConfig": {
    "titleColor": "#111111",
    "titleBackPath": "",
    "titleBackBase64": "",
    "titleClosePath": "",
    "titleCloseBase64": "",
    "bannerImg": "",
    "agrtUnSelColor": "#c5c5c5",
    "agrtSelBgColor": "#ff6a00",
    "agrtAgreeColor": "#333333",
    "agrtColor": "#ff6a00",
    "startBtnColor": "#ffffff",
    "agrtBotTipsColor": "#333333",
    "startBtnDisColor": "#ffffff",
    "startBtnBgColor": "#ff6a00",
    "startBtnDisBgColor": "#d9d9d9",
    "elderBtnDisColor": "#ffffff",
    "elderBtnBgColor": "#f0f0f0",
    "elderBtnDisBgColor": "#d9d9d9",
    "exitBtnColor": "#333333",
    "exitBtnBgColor": "#ffffff",
    "elderBtnColor": "#ff6a00",
    "rareFormEntBtnColor": "#ff6a00",
    "permissionToastBgColor": "#ffffff",
    "permissionToastTitleColor": "#000000",
    "permissionToastMsgColor": "#000000",
    "dialogExitTitleColor": "#000000",
    "dialogExitMsgColor": "#000000",
    "dialogExitCancelColor": "#0E83E6",
    "dialogExitConfirmColor": "#0E83E6",
    "dialogPermissionFailedTitleColor": "#000000",
    "dialogPermissionFailedMsgColor": "#000000",
    "dialogPermissionFailedConfirmColor": "#0E83E6",
    "dialogSupportFailedTitleColor": "#000000",
    "dialogSupportFailedMsgColor": "#000000",
    "dialogSupportFailedConfirmColor": "#0E83E6",
    "dialogNetworkFailedTitleColor": "#000000",
    "dialogNetworkFailedMsgColor": "#000000",
    "dialogNetworkFailedConfirmColor": "#0E83E6"
  },
  "faceConfig": {
    "faceBgColor": "#FFFFFF",
    "faceTitleColor": "#000000",
    "circleTxtBgAlpha": "0.25",
    "dialogBgAlpha": "0.25",
    "faceProgressStartColor": "#dfe6eb",
    "faceProgressEndColor": "#FF6A00",
    "circleTxtColor": "#ffffff",
    "exitIconPath": "",
    "exitIconBase64": "",
    "submitTextColor": "#E4E4E4",
    "submitLoadingIconBase64": "",
    "submitLoadingIconPath": "",
    "dialogExitTitleColor": "#000000",
    "dialogExitMsgColor": "#000000",
    "dialogExitCancelColor": "#0E83E6",
    "dialogExitConfirmColor": "#0E83E6",
    "dialogTimeOutTitleColor": "#000000",
    "dialogTimeOutMsgColor": "#000000",
    "dialogTimeOutConfirmColor": "#0E83E6",
    "dialogNetworkFailedTitleColor": "#000000",
    "dialogNetworkFailedMsgColor": "#000000",
    "dialogNetworkFailedConfirmColor": "#0E83E6",
    "dialogArchSysFailedTitleColor": "#000000",
    "dialogArchSysFailedMsgColor": "#000000",
    "dialogArchSysFailedConfirmColor": "#0E83E6",
    "dialogTooManyRetriesTitleColor": "#000000",
    "dialogTooManyRetriesMsgColor": "#000000",
    "dialogTooManyRetriesConfirmColor": "#0E83E6",
    "dialogInterruptTitleColor": "#000000",
    "dialogInterruptMsgColor": "#000000",
    "dialogInterruptConfirmColor": "#0E83E6",
    "dialogInterruptCancelColor": "#0E83E6",
    "dialogSDKErrTitleColor": "#000000",
    "dialogSDKErrMsgColor": "#000000",
    "dialogSDKErrConfirmColor": "#0E83E6",
    "dialogCamOpenFailedTitleColor": "#000000",
    "dialogCamOpenFailedMsgColor": "#000000",
    "dialogCamOpenFailedConfirmColor": "#0E83E6",
    "dialogCamOpenFailedCancelColor": "#0E83E6",
    "noticeIconPath": "",
    "noticeTxtColor": "#1677FF",
    "noticeBgColor": "#0F1677FF"
  }
}

字段详细说明

展开折叠面板查看字段详细说明。

ZIMFacade zimFacade = ZIMFacadeBuilder.create(MainActivity.this);
HashMap<String, String> extParams = new HashMap<>();
//如需打开刷脸页业务提示开关（默认可不设置），请设置此项,需要结合自定义UI的配置文件使用
extParams.put(ZIMFacade.ZIM_EXT_PARAMS_KEY_NEED_FACE_NOTICE, ZIMFacade.ZIM_EXT_PARAMS_VAL_NEED_FACE_NOTICE_TRUE);
zimFacade.verify(certifyId, true, extParams, new ZIMCallback() {
    @Override
    public boolean response(final ZIMResponse response) {
        return true;
    }
});

自定义UI文案

目前仅支持自定义引导页和活体认证页的展示文案。

接口说明

SDK中提供了自定义UI文案的接口：setCustomTxtConfig。

/**
 * @description 设置自定义UI。
 * @param {int} paramType 参数类型，可传范围（ZIMFacade.ZIM_EXT_PARAMS_VAL_ZIM_EXT_PARAMS_CONFIG_ASSETS_NAME
 * /ZIMFacade.ZIM_EXT_PARAMS_VAL_ZIM_EXT_PARAMS_CONFIG_FILE_PATH
 * /ZIMFacade.ZIM_EXT_PARAMS_VAL_ZIM_EXT_PARAMS_CONFIG_FILE_JSON）
 * @param {String} params 参数值，paramType相对应的值
 * @return 配置文件检测出的异常信息。
 */
public String setCustomTxtConfig(int paramType, String param) {
 ...
}

• 参数说明

  名称	类型	说明
  paramType	int	配置自定义入参的类型，可选值： ZIMFacade.ZIM_EXT_PARAMS_VAL_ZIM_EXT_PARAMS_CONFIG_ASSETS_NAME： 传入App assets文件类型，param需要传入assets文件名称。 ZIMFacade.ZIM_EXT_PARAMS_VAL_ZIM_EXT_PARAMS_CONFIG_FILE_PATH： 传入设备本地路径，params需要传入配置文件的设备绝对路径地址。 ZIMFacade.ZIM_EXT_PARAMS_VAL_ZIM_EXT_PARAMS_CONFIG_FILE_JSON： 传入JSON字符串，params传入JSON格式的数据。
  param	String	与paramType配套调用。

• 返回值：String类型，当SDK对param内容解析遇到错误或出现异常信息时会通过提示信息的方式返回。当配置参数无效时，请重点关注返回值信息。

示例代码

//传入文件路径
File file = new File(getFilesDir() + "/dtf/config_test/DTFConsumTxtConfig.json");
String path = file.getAbsolutePath();
int paramType = ZIMFacade.ZIM_EXT_PARAMS_VAL_ZIM_EXT_PARAMS_CONFIG_FILE_PATH;
customUIErrMsg = zimFacade.setCustomTxtConfig(paramType, path);

//传入assets文件名
String fileName = "DTFConsumTxtConfig.json";
int paramType = ZIMFacade.ZIM_EXT_PARAMS_VAL_ZIM_EXT_PARAMS_CONFIG_ASSETS_NAME;
customUIErrMsg = zimFacade.setCustomTxtConfig(paramType, fileName);

//传入json字符串
String jsonConfig="";
int paramType = ZIMFacade.ZIM_EXT_PARAMS_VAL_ZIM_EXT_PARAMS_CONFIG_FILE_JSON;
customUIErrMsg = zimFacade.setCustomTxtConfig(paramType, jsonConfig);

字段定义

字段列表

{
  "guideConfig": {
    "titleText": "刷脸认证",
    "agrtTopTipsText": "请先勾选协议",
    "agrtAgreeText": "同意",
    "agrtText": "《认证服务协议》",
    "agrtBotTipsText": "同意认证后，将获取您的摄像头权限用于人脸识别验证身份",
    "startBtnText": "开始认证",
    "elderBtnText": "长辈模式认证",
    "exitBtnText": "暂不认证",
    "authPermissionSDKName": "实人认证",
    "authPermissionAPPName": "阿里云实人认证",
    "authPermissionCamera": "相机",
    "authPermissionAudio": "录音",
    "authPermissionScreenEvidence": "录屏",
    "authPermissionToastTitle": "",
    "authPermissionToastMsg": "",
    "dialogExitTitle": "确定退出吗?",
    "dialogExitMsg": "露个脸就能通过",
    "dialogExitConfirm": "确定",
    "dialogExitCancel": "取消",
    "dialogPermissionFailedTitle": "认证失败",
    "dialogPermissionFailedMsg": "请确认相关权限已开启后再次发起",
    "dialogPermissionFailedConfirm": "确认",
    "dialogNetworkFailedTitle": "网络不给力",
    "dialogNetworkFailedMsg": "请检查网络",
    "dialogNetworkFailedConfirm": "确定",
    "dialogSupportFailedTitle": "当前系统不支持刷脸",
    "dialogSupportFailedMsg": "刷脸仅在高版本及以上系统可用",
    "dialogSupportFailedConfirm": "确定"
  },
  "faceConfig": {
    "faceNotFound": "没有检测到脸",
    "faceTooFar": "靠近一点",
    "faceTooClose": "离远一点",
    "faceNotIn": "把脸移入圈内",
    "badPitch": "请正对手机",
    "badYaw": "请正对手机",
    "faceTooMore": "请保持单人操作",
    "faceIsMoving": "再清晰一点",
    "faceBrightless": "脸部亮一点",
    "faceBadQuality": "请露出正脸",
    "eyesOnScreen": "请注视屏幕",
    "blink": "眨眨眼",
    "leftYaw": "向左摇头",
    "rightYaw": "向右摇头",
    "stackTime": "请保持不动",
    "isBlur": "再清晰一点",
    "hasHat" : "请摘掉帽子",
    "faceOcclusion" : "请移除遮挡"
    "faceInitTxt": "请正对屏幕",
    "faceTitleBlink": "拿起手机，眨眨眼",
    "leftYawLiveness": "拿起手机，向左摇头",
    "rightYawLiveness": "拿起手机，向右摇头",
    "photinusCommTips": "请把脸移入圈内保持不动",
    "qualityTitle": "勿遮挡、倾斜、逆光拍摄",
    "processing": "正在处理",
    "dialogTimeOutTitle": "操作超时",
    "dialogTimeOutMsg": "正对手机，更容易成功",
    "dialogTimeOutConfirm": "再试一次",
    "dialogInterruptTitle": "验证中断",
    "dialogInterruptConfirm": "再试一次",
    "dialogInterruptCancel": "退出",
    "dialogTooManyRetriesTitle": "本次操作失败",
    "dialogTooManyRetriesMsg": "刷脸失败次数过多，请稍后再试",
    "dialogTooManyRetriesConfirm": "我知道了",
    "dialogExitTitle": "确定退出吗?",
    "dialogExitMsg": "露个脸就能通过",
    "dialogExitConfirm": "确定",
    "dialogExitCancel": "取消",
    "dialogCamOpenFailedTitle": "摄像头打开异常",
    "dialogCamOpenFailedMsg": "请重启app或手机后再次尝试",
    "dialogCamOpenFailedConfirm": "确定",
    "dialogCamOpenFailedCancel": "取消",
    "dialogArchSysFailedTitle": "当前系统不支持刷脸",
    "dialogArchSysFailedMsg": "刷脸仅在高版本及以上系统可用",
    "dialogArchSysFailedConfirm": "确定",
    "dialogSDKErrTitle": "本次操作失败",
    "dialogSDKErrMsg": "抱歉，系统出错了，请再试一次",
    "dialogSDKErrConfirm": "确定",
    "dialogNetworkFailedTitle": "网络不给力",
    "dialogNetworkFailedMsg": "请检查网络",
    "dialogNetworkFailedConfirm": "确定",
    "verifyNotice": "您正在进行实人认证，请确保本人操作！"
  }
}

字段详细说明

展开折叠面板查看字段详细说明。

ZIMFacade zimFacade = ZIMFacadeBuilder.create(MainActivity.this);
HashMap<String, String> extParams = new HashMap<>();
//如需打开刷脸页业务提示开关（默认可不设置），请设置此项,需要结合自定义UI的配置文件使用
extParams.put(ZIMFacade.ZIM_EXT_PARAMS_KEY_NEED_FACE_NOTICE, ZIMFacade.ZIM_EXT_PARAMS_VAL_NEED_FACE_NOTICE_TRUE);
zimFacade.verify(certifyId, true, extParams, new ZIMCallback() {
    @Override
    public boolean response(final ZIMResponse response) {
        return true;
    }
});

合规权限提醒

SDK为了保证基础功能的运行需要向客户申请对应功能的权限，为了保证您的应用对客户展示合规，SDK内部提供了权限获取以及使用说明提醒弹窗，该功能默认关闭，当您需要使用时请通过verify接口进行开启。

开关接口

接口说明

请参考对应方案的Verify接口函数定义。

示例代码

 HashMap<String, String> extParams = new HashMap<>();
//如获取权限时需要SDK弹出权限提醒toast,请设置此项
extParams.put(ZIMFacade.ZIM_EXT_PARAMS_KEY_NEED_PERMISSION_TOAST, ZIMFacade.ZIM_EXT_PARAMS_VAL_NEED_PERMISSION_TOAST_TRUE);
//如想修改SDK权限提醒toast的显示持续时间，请设置此项，单位为毫秒
extParams.put(ZIMFacade.ZIM_EXT_PARAMS_KEY_NEED_PERMISSION_TOAST_DURATION, "2000");
zimFacade.verify(certifyId, true, extParams, new ZIMCallback() {
    @Override
    public boolean response(ZIMResponse response) {
        if (null != response && 1000 == response.code) {
            // 认证成功
            Toast.makeText(getApplicationContext(),
            "认证成功\n" +
            "code: " + response.code + "\n" +
            "reason: " + response.reason,
            Toast.LENGTH_LONG).show();
            } else {
            // 认证失败
            Toast.makeText(getApplicationContext(),
            "认证失败\n" +
            "code: " + response.code + "\n" +
            "reason: " + response.reason,
            Toast.LENGTH_LONG).show();
            }

            return true;
        }
});

弹窗自定义接口

当Android SDK默认的弹框不足以满足业务诉求时，您可以通过ZIMUICustomListener接口自定义弹窗能力。

接口说明

/**
 * 设置UI自定义回调
 * @param uiListener
 */
public void setCustomUIListener(ZIMUICustomListener uiListener) {
 ....
}

public interface ZIMUICustomListener {
 ......

 /**
 * SDK请求权限时回调通知
 * @return 是否实现权限提示弹窗
 */
 boolean onPermissionRequest(Activity activity, List<String> requestPerms, String verifyType);
}

• 参数说明

  名称	类型	说明
  activity	Activity	当前请求权限的Activity。
  requestPerms	List<String>	当前请求权限的列表。
  verifyType	String	当前请求权限的业务。 FACE：活体业务。 OCR：证件业务。 WISH：多因子意愿业务。

• 返回值：bool类型。当您需要自行处理弹窗时，返回设置为true；若需要默认弹窗，则返回值设置为false。

示例代码

/**
* @return 是否实现权限提示弹窗
*/
zimFacade.setCustomUIListener(new ZIMUICustomListener() {
 ...
 @Override
 public boolean onPermissionRequest(Activity activity, List<String> requestPerms, String verifyType) {
 Toast.makeText(activity, "PermissionRequest", Toast.LENGTH_SHORT).show();
 return true;
 }
 });=
